Easy UPS On-Line
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions
For small to medium businesses, APC by Schneider Electric delivers a new category of UPSs designed for essential power protection needs even in the most unstable power conditions. APC Easy UPS 1 Ph Online is a versatile, high quality, cost competitive UPS developed to handle a wide voltage range, inconsistent power conditions and delivering the quality millions of IT professionals trust around the world.
- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Easy UPS
- Product Type
- Double Conversion Online UPS
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Receptacle Type
- IEC 60320 C13
- Receptacle Detail
- 4 x IEC 60320 C13
- Number of Battery & Surge Outlets
- 8
- Transfer Time
- 0 ns
- Phase
- Single Phase
- Application/Usage
- Business
- Power Description
- Load Capacity (VA)
- 2000 VA
- Load Capacity (Watt)
- 1600 W
- Input Voltage Range
- 160 V AC - 280 V AC
- Output Voltage
- 230 V AC
- 240 V AC
- Input Frequency
- 70 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Management
- Alarm
- On Battery
- Low Battery
- Overload
- Controls/Indicators
- Status Indicators
Multi-function LCD
- Interfaces/Ports
- Serial Port
- Yes
- EPO Port
- No
- USB (HID Compliant) Port
- Yes
- Battery Information
- DC System Voltage
- 12 V DC
- Number of Batteries
- 4
- Battery Characteristics
- Maintenance-free, Sealed, Leak-proof
- Battery Chemistry
- Lead Acid
- Battery Size
- 12V
- Battery Capacity
- 9000 mAh
- Backup/Run Time (Full Load)
- 4 Minute
- Backup/Run Time (Half Load)
- 10 Minute
- Typical Battery Recharge Time
- 4 Hour
- Replaceable Battery
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 104°F (40°C)
- Storage Temperature
- -4°F (-20°C) - 122°F (50°C)
- Maximum Operating Elevation
- 9842.52 ft
- Maximum Storage Elevation
- 48437.01 ft
- Operating Humidity
- 0% - 95%
- Storage Relative Humidity
- 0% - 95%
- Physical Characteristics
- Product Color
- Black
- Height
- 9.4"
- Width
- 5.7"
- Depth
- 15.7"
- Form Factor
- Tower
- Weight (Approximate)
- 37.04 lb
- Miscellaneous
- Package Contents
- Easy UPS SRV 2000VA 230V
- Basic UPS signalling RS-232 cable
- CD with software
- USB cable
- User manual
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
