Buy Arista Networks 7050TX-48 Layer 3 Switch

Arista Networks 7050TX-48 Layer 3 Switch

Part: 3163793
Model: DCS-7050TX-48-R

$18,965.00

Availability

Out of Stock

General Information
- Manufacturer
- Arista Networks, Inc
- Manufacturer Website Address
- http://www.aristanetworks.com
- Brand Name
- Arista Networks
- Product Series
- 7050TX
- Product Type
- Layer 3 Switch

The Arista 7050TX are members of the Arista 7050X Series and key components of the Arista portfolio of data center switches. The Arista 7050X Series are purpose built 10/40GbE data center switches in compact and energy efficient form factors with wire speed layer 2 and layer 3 features combined with low latency and advanced features for software defined cloud networking.

Increased adoption of 10 Gigabit Ethernet servers coupled with applications using higher bandwidth is accelerating the need for dense 10 and 40 Gigabit Ethernet switching. The 7050TX Series support from 32 to 96 ports of auto-negotiating 100Mb/1Gb/10GBASE-T and from 4 to 12 ports of 10/40GbE that allow customers to design large leaf and spine networks to accommodate the east-west traffic patterns found in modern data centers. The 7050TX backwards compatibility with existing gigabit Ethernet cabling reduces the cost of migrating to 10 Gigabit Ethernet and offers an easy evolution.

Warranty
- Limited Warranty
- 1 Year

Interfaces/Ports
- Total Number of Network Ports
- 32
- Token Ring Port
- No
- LRE Port
- No
- Bypass
- No
- Modular
- No
- Management Port
- Yes
- USB
- Yes
- Number of Network (RJ-45) Ports
- 32
- Port/Expansion Slot Details
- 4 x 40 Gigabit Ethernet Expansion Slot
- 32 x 10 Gigabit Ethernet Network

Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- 10 Gigabit Ethernet
- 40 Gigabit Ethernet
- Network Technology
- 10GBase-T
- 40GBase-X

I/O Expansions
- Total Number of Expansion Slots
- 4.0
- Expansion Slot Type
- QSFP+

Network & Communication
- Layer Supported
- 3

Management & Protocols
- Manageable
- Yes
- Management
- - QoS
  - CLI
  - DHCP
  - Telnet
  - SNMP v1, 2, 3
  - Syslog
  - MIB
  - VLAN
  - Web-based Management
  - sFlow

Memory
- Standard Memory
- 4 GB
- Memory Technology
- DRAM
- Flash Memory
- 4 GB

Power Description
- PoE (RJ-45) Port
- No
- Power Source
- Power Supply
- Redundant Power Supply Supported
- Yes

Physical Characteristics
- Form Factor
- Rack-mountable
- Height
- 1.8"
- Width
- 19"
- Depth
- 15.8"
- Weight (Approximate)
- 17 lb

Miscellaneous
- Certifications & Standards
- EMC:
  - Emissions: FCC, EN55022, EN61000-3-2,
  - EN61000-3-3 or EN61000-3-11
  - EN61000-3-12 (as applicable)
  - Immunity: EN55024
  - Emissions and Immunity: EN300 386
  Safety:
  - UL/CSA 60950-1, EN 60950-1, IEC 60950-1
  - CB Scheme with all country differences
  Certifications:
  - North America (NRTL)
  - European Union (EU)
  - BSMI (Taiwan)
  - C-Tick (Australia)
  - CCC (PRC)
  - MSIP (Korea)
  - EAC (Customs Union)
  - VCCI (Japan)
  European Union Directives:
  - 2006/95/EC Low Voltage Directive
  - 2004/108/EC EMC Directive
  - 2011/65/EU RoHS Directive
  - 2012/19/EU WEEE Directive
- Environmentally Friendly
- Yes
