- General Information
- Manufacturer
- CP Technologies
- Manufacturer Website Address
- http://www.cptechusa.com
- Brand Name
- LevelOne
- Product Type
- Network Camera
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/3.2"
- White Balance Modes
- AWB
- Color Supported
- Color
- Monochrome
- Field of View
- 28.88° to 66.62°
- Effective Camera Resolution
- 5 Megapixel
- Video
- Video Formats
- MJPEG
- H.264
- Maximum Video Resolution
- 2592 x 1944
- Maximum Frame Rate
- 30 fps
- Lens
- Lens Type
- Zoom
- Minimum Focal Length
- 2.80 mm
- Maximum Focal Length
- 12 mm
- Lens Included
- Yes
- Maximum Aperture
- f/1.4
- Optical Zoom
- 4.3x
- Focus Modes
- Manual
- Exposure
- Shortest Shutter Speed
- 1/10000 Second
- Longest Shutter Speed
- 1/5 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet
- Yes
- Ethernet Technology
- Fast Ethernet
- Protocols
- TCP
- UDP
- HTTP
- HTTPS
- DHCP
- PPPoE
- RTP
- RTSP
- IPv6
- DNS
- DDNS
- NTP
- ICMP
- ARP
- IGMP
- SMTP
- FTP
- UPnP
- SNMP
- Bonjour
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Audio Line In
- Yes
- Audio Line Out
- Yes
- Power Description
- Maximum Power Consumption
- 6.49 W
- Physical Characteristics
- Mount Type
- Wall Mount
- Ceiling Mount
- Form Factor
- Dome
- Durability
- Vandal Resistant
- Vandal Proof
- Height
- 5.7"
- Width
- 5.7"
- Depth
- 4.5"
- Weight (Approximate)
- 1.19 lb
- Miscellaneous
- Features
- Day/Night
- SD Card Local Storage
- Back Light Compensation (BLC)
- 2D Noise Reduction
- Indoor/Outdoor
- Outdoor
- Package Contents
- FCS-3064 Network Camera
- Screw Kit
- Quick Installation Guide
- Resource CD (User Manual, Utility,QIG)
- Mounting Kit
- System Requirements
- Operating Systems: Microsoft Windows 7/Vista/XP
- Certifications & Standards
- IK09
- CE
- FCC
- ONVIF
- NEMA 4X
- Impact Protection Rating
- IK09
- Country of Origin
- Taiwan
