HDD + SSD hybrid-structure AMD Ryzen™ 1U rackmount NAS with up to 6 cores/12 threads

Powered by AMD's powerful Ryzen™ processor, the TS-977XU-RP delivers high system performance with up to 6 cores/12 threads and Turbo Core up to 3.9 GHz. The TS-977XU-RP features a hybrid structure with four 3.5-inch HDD and five 2.5-inch SSD drive bays, allowing for enabling SSD caching and Qtier™ auto-tiering technology to greatly boost IOPS to meet the performance requirements of demanding applications. The TS-977XU-RP features two SFP+ 10GbE ports and two Gigabit ports for high-speed connectivity, providing businesses and organizations with an ideal solution for quickly deploying a high-bandwidth, high-reliability storage environment. The TS-977XU-RP also features a redundant power supply to ensure maximum system uptime.

• Install up to five SSDs in the 2.5-inch drive bays to enable SSD caching and Qtier for optimal system performance.

• Two 10GbE SFP+ ports provide higher bandwidth to empower applications like virtualization, 4K video editing and file sharing.

• PCIe expandability allows for installing QM2 expansion card, USB 3.2 Gen 2 (10Gbps) cards, or wireless network cards.

• Snapshots add an extra layer of protection for disaster recovery plans. You can set a custom snapshot schedule and can use snapshots to recover data from a local or remote NAS.

• Scalable storage supporting virtualization, containerized apps, centralized storage, backup, sharing, and disaster recovery.

• Besides using QNAP storage expansion enclosures, you can also leverage QNAP VJBOD technology to use the unused storage space from other NAS.

Top-class hardware engineering with high I/O expandability

The hardware design of the TS-977XU-RP provides exceptional system performance and expandability to fulfill diverse application requirements.

Absolute performance with AMD Ryzen™ and up to 64GB RAM

Powered by a high-performance AMD Ryzen™ 3 1200 processor or Ryzen™ 5 2600 processor with AES-NI encryption acceleration and up to 64GB DDR4 RAM, the TS-977XU-RP delivers aggressive yet power-smart performance to meet your multitasking demands. For resource-demanding business applications such as VDI, R&D, private cloud, and server virtualization, look no further than the TS-977XU-RP.

Extend hardware warranty up to 5 years

The TS-977XU-RP is backed by a 3-year warranty at no extra cost. If needed, you can purchase a warranty extension that increases your coverage up to 5 years.

Hybrid structure for enabling SSD and tiered storage

The TS-977XU-RP features an HDD+ SSD hybrid structure (including five 2.5-inch and four 3.5-inch drive bays), allowing you to leverage the benefits of both hard drives and SSD to provide high storage capacity and high performance. Qtier™ Technology empowers the TS-977XU-RP with automatic tiering that continuously optimizes storage utilization across high-performance SSD and high-capacity hard drives. The new Qtier™ 2.0 features IO-awareness that empowers SSD-tiered storage with a cache-like reserved space to handle burst I/O in real time, greatly maximizing the advantages of SSD.

• General Information
• • Manufacturer
  • QNAP Systems
  • Manufacturer Website Address
  • http://www.qnap.com
  • Brand Name
  • QNAP
  • Product Series
  • TS-x77XU
  • Product Type
  • SAN/NAS Storage System

• Warranty
• • Limited Warranty
  • 3 Year
