- General Information
- Manufacturer
- Tyan Computer Corp
- Manufacturer Website Address
- http://www.tyan.com
- Brand Name
- Tyan
- Product Series
- FT48
- Product Type
- Barebone System
- Warranty
- Limited Warranty
- 3 Year
- Processor
- Number of Processors Supported
- 2
- Processor Socket
- Socket B LGA-1366
- Processor Supported
- Xeon
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- 5520
- Memory
- Maximum Memory Supported
- 64 GB
- Memory Technology
- DDR3 SDRAM
- Memory Standard
- DDR3-1333/PC3-10600
- Total Number of Memory Slots
- 8
- Controllers
- Controller Type
- Serial Attached SCSI (SAS)
- Display & Graphics
- Graphics Controller Model
- AST2050
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- I/O Expansions
- Number of Total Expansion Bays
- 7
- Number of External 5.25" Bays
- 3
- Number of 3.5" Bays
- 4
- Total Number of Expansion Slots
- 7
- Number of PCI Slots
- 1
- Number of PCI Express x4 Slots
- 1
- Number of PCI Express x8 Slots
- 1
- Number of PCI Express x16 Slots
- 4
- Interfaces/Ports
- Total Number of USB Ports
- 6
- Number of USB 2.0 Ports
- 6
- Network (RJ-45)
- Yes
- VGA
- Yes
- Operating System
- Operating System Supported
- Windows XP Professional
- Windows XP Professional x64
- Windows Vista Ultimate
- Windows Vista Ultimate x64
- Windows Server 2003 Standard
- Windows Server 2003 Standard x64
- Windows Server 2008
- Windows Server 2008 x64
- Windows 7
- Windows 7 x64
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Number of Power Supplies Installed
- 2
- Maximum Power Supply Wattage
- 1300 W
- Physical Characteristics
- Form Factor
- Rack-mountable
- Rack Height
- 4U
- Height
- 6.9"
- Width
- 16.8"
- Depth
- 27.5"
- Miscellaneous
- Additional Information
QuickPath Technology:
- QuickPath Interconnect supports up to 6.4 GT/s
Expansion Slot Detail:
- PCI Express x8 slot has the bus speed of PCI Express x4
- Environmentally Friendly
- Yes
