The S5512 not only empowers you in today's demanding IT environment but also offers a smooth path for future application upgradeability. All of these rich feature sets provides the S5512 with the power and flexibility to meet demanding requirements for today's IT environments.
- General Information
- Manufacturer
- Tyan Computer Corp
- Manufacturer Website Address
- http://www.tyan.com
- Brand Name
- Tyan
- Package Type
- Retail
- Product Type
- Server Motherboard
- Warranty
- Limited Warranty
- 3 Year
- Processor & Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C204
- Total Processor Supported
- 1
- Processor Technology
- Hyper-Threading Technology
- Virtualization Technology
- Processor Socket
- Socket H2 LGA-1155
- Processor Supported
- Xeon
- Core i3
- 64-bit Processing
- Yes
- Memory
- Number of Memory Slots
- 4
- Memory Form Factor
- DIMM
- Maximum Memory Supported
- 32 GB
- Memory Standard
- DDR3-1333/PC3-10600
- DDR3-1066/PC3-8500
- DDR3-800/PC3-6400
- Memory Technology
- DDR3 SDRAM
- Memory Speed Supported
- 1333 MHz
- 1066 MHz
- 800 MHz
- I/O Controller
- Controller Type
- 6Gb/s SAS
- Serial ATA/300
- Serial ATA/600
- RAID Supported
- Yes
- RAID Levels
- 0
- 1
- 1E
- 1+0
- 5
- Video
- Onboard Video
- CPU Dependent Video
- Graphics Controller Model
- AST2150
- Graphics Controller Memory
- 128 MB
- I/O Expansions
- Total Number of Expansion Slots
- 5
- Number of PCI Slots
- 1
- PCI Express Standard
- PCI Express 2.0
- Total Number of PCI Express Slots
- 4
- Number of PCI Express x1 Slots
- 2
- Number of PCI Express x8 Slots
- 1
- Number of PCI Express x16 Slots
- 1
- Interfaces/Ports
- Total Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 4
- Serial Port
- Yes
- VGA
- Yes
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 2
- Onboard Interfaces
- Number of SATA Interfaces
- 6
- Number of SAS Interfaces
- 8
- Total Number of Onboard USB Ports
- 6
- Number of Onboard USB 2.0 Ports
- 6
- Onboard Serial Header
- Yes
- Onboard LEDs Header
- Yes
- Controls/Indicators
- Buttons & Keys
- Power
- Power Description
- Operating Power Consumption
- 95 W
- Power Supply Supported
- EPS12V
- Physical Characteristics
- Form Factor
- ATX
- Width
- 12"
- Depth
- 9.6"
- Miscellaneous
- Package Contents
- S5512 Server Motherboard
- 1 x User Manual
- 1 x Quick Reference Guide
- 1 x Installation CD
- 1 x IO Shield
- 8 x SAS/SATA Signal Cables
- Certifications & Standards
- FCC
- CE
- ErP
- EuP
- Environmentally Friendly
- Yes
