- General Information
- Manufacturer
- Tyan Computer Corp
- Manufacturer Website Address
- http://www.tyan.com
- Brand Name
- Tyan
- Product Series
- GT24
- Product Type
- Barebone System
- Warranty
- Limited Warranty
- 3 Year
- Processor
- Number of Processors Supported
- 2
- Processor Socket
- Socket F LGA-1207
- Processor Supported
- Opteron
- Chipset
- Chipset Manufacturer
- NVIDIA
- Chipset Model
- nForce Pro 3600
- Memory
- Maximum Memory Supported
- 128 GB
- Memory Technology
- DDR2 SDRAM
- Memory Standard
- DDR2-667/PC2-5300
- Total Number of Memory Slots
- 16
- Storage
- Optical Drive Type
- DVD-Reader
- Optical Media Supported
- DVD-ROM
- Controllers
- Controller Type
- Serial ATA/300
- RAID Supported
- Yes
- RAID Levels
- 0, 1, 0+1, 5
- Display & Graphics
- Graphics Controller Model
- ES1000
- Graphics Memory Capacity
- 32 MB
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- I/O Expansions
- Number of Total Expansion Bays
- 5
- Number of External 5.25" Bays
- 1
- Number of 3.5" Bays
- 4
- Total Number of Expansion Slots
- 1
- Number of PCI Express x16 Slots
- 1
- Interfaces/Ports
- Total Number of USB Ports
- 4
- Network (RJ-45)
- Yes
- VGA
- Yes
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Number of Power Supplies Installed
- 1
- Maximum Power Supply Wattage
- 650 W
- Physical Characteristics
- Form Factor
- Rack-mountable
- Rack Height
- 1U
- Height
- 1.7"
- Width
- 17.2"
- Depth
- 25.4"
- Weight (Approximate)
- 39.68 lb
- Miscellaneous
- Package Contents
- GT24 B2932-SI Barebone System
- 1 x MB User Manual
- 1 x BB User Manual
- 1 x TYAN Installation CD
- 1 x CHSK-0052, AMD 1207-pin CPU Heatsink
- 1 x CHSK-0053, AMD 1207-pin CPU Heatsink
- 1 x CRAL-0031, Sliding Rail Kit for KGT24
- 1 x CEAR-0050, Mounting Ear Kit for GT20/ GT24
- 1 x HDD Screw Pack
- 1 x CFAK-0020 Standard FDD Accessory Kit
- 1 x CCBL-0310, US Type Power Cord
- 1 x CCBL-0300, EU Type Power Cord
- Additional Information
Expansion Slot Detail:
- PCI Express 16 slot has the bus speed of PCI Express x8
Memory Detail:
- Support up to 64GB Registered ECC DDR2 800 memory (4 DIMMs per CPU)
- Environmentally Friendly
- Yes
