- General Information
- Manufacturer
- CP Technologies
- Manufacturer Website Address
- http://www.cptechusa.com
- Brand Name
- LevelOne
- Product Type
- Network Camera
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/3.2"
- White Balance Modes
- AWB
- Color Supported
- Color
- Field of View
- 83.3°
- Effective Camera Resolution
- 3 Megapixel
- Video
- Video Formats
- MJPEG
- H.264
- Maximum Video Resolution
- 2048 x 1536
- Maximum Frame Rate
- 30 fps
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 2.93 mm
- Lens Included
- Yes
- Maximum Aperture
- f/2
- Focus Modes
- Fixed Focus
- Exposure
- Shortest Shutter Speed
- 1/10000 Second
- Longest Shutter Speed
- 1/5 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet
- Yes
- Ethernet Technology
- Fast Ethernet
- Protocols
- ARP
- IGMP
- SMTP
- FTP
- UPnP
- SNMP
- Bonjour
- UDP
- HTTP
- HTTPS
- DHCP
- PPPoE
- RTP
- RTSP
- IPv6
- DNS
- DDNS
- NTP
- ICMP
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Maximum Power Consumption
- 2.91 W
- Physical Characteristics
- Mount Type
- Wall Mount
- Ceiling Mount
- Form Factor
- Dome
- Durability
- Vandal Resistant
- Vandal Proof
- Height
- 4.3"
- Width
- 4.3"
- Depth
- 2.3"
- Weight (Approximate)
- 7.13 oz
- Miscellaneous
- Features
- SD Card Local Storage
- 2D Noise Reduction
- Back Light Compensation (BLC)
- Package Contents
- Fixed Dome Network Camera, 3-Megapixel, PoE 802.3af
- Mounting Kit
- Screw Kit
- Quick Installation Guide
- Resource CD (User Manual, Utility, QIG)
- System Requirements
- Operation Systems: Microsoft Windows 8/7/Vista/XP
- Certifications & Standards
- IK08
- CE
- FCC
- Impact Protection Rating
- IK08
- Country of Origin
- Taiwan
